D10 – Quick Release Drop Test Hook
The D10 is a 10-ton load drop hook that enables you to drop the load into the air safely and from a distance when the order is given, using the remote control.
Remote Load Drop Hook: Efficient and Reliable
The D10 is a 10 Tonne automatic drop test hook that allows you to drop any load safely and at a distance with the use of the remote control.
No need to climb, use of ropes or cables to drop the load. Release the load effortlessly. from a safe distance.
Experience the convenience of our automate quick drop system, making your workflow seamless and secure.
Check out our range of automatic release hooks
See the Remote Drop Test Hook in action
How Does Our Drop Test Release Hook Work?
*Before operating D10 ensure the load transfer and release area is clear of personnel and equipment that could be affected in the event of load release.
In Detail: Quick Release Drop Tester Features
The Minimum Releasable Weight is 0 kgs/0 lbs.*
High-Brightness LED
Status Indicator
The color of the LEDs indicates the state of the hook.
Green: D10 is Open / Unlocked
Red: Transitioning: Watch out! Load about to drop.
Blue: D10 is Closed / locked
White: Low Battery
Precision Load Cell in Quick Release Drop Tester
(Coming soon)
The D10 can be equipped with a load cell for precise load measurements during the lifting process.
Our load cells provide quick and accurate readings, offering affordability and a longer lifespan compared to other sensors. Primarily used for weighing and preventing overloads, the load cell, when combined with the remote control, transforms our automatic drop test hook into a sophisticated and precise weighing scale with advanced features.
Specifications of Our Quick Release Hook Drop Test
| Nominal Load (Ln) | 10t |
| Accuracy Class | 0.5% |
| Minimum dead load | 0% Ln |
| Service load | 150% Ln |
| Ultimate load limit | >400% Ln |
| Total error | < ±0.5 % Ln |
| Repeatability error | < ±0.2% Ln |
| Temperature effect on zero | < ±0.2% Ln/ 5ºC |
| Temperature effect on sensitivity | < ±0.2% Ln/ 5ºC |
| Creep error (30 min) | < ±0.1% Sn |
| Temperature compensation | -20 to +60 ºC |
| Storage temperature | – 40 to +95ºC |
| Service temperature limits | -20 to +90 ºC |
| Excitation voltage | 3…15 V |
| Imput impedance | 400 ±30 Ohm |
| Environmental Protection | IP66 |
| Material | Stainless steel |
| Cable gland + Shielded cable 4 wires | 5M |
High-Capacity Battery
With the high-capacity battery, a simple 3 hour charge allows for
a full day of productivity.
The battery remains protected from accidental impacts as the slot cover is protected
with a safety lock which protects the battery from falling in case of impact.
Autoclose Mode for Secure Operations
The safety pin activates the autoclose function.
In order to insert the safety pin, the hook must be closed manually. If the hook is open, the safety pin cannot be inserted.
Once the safety pin is properly inserted and rotated to activate the autoclose system, it locks and cannot be removed during the closing process.
When modifying the position of the safety pin and inserting it in the bottom slot, the autoclose sensor activates itself and gives the order to lock the safety latch.
Dual Remote Controlled Release for Quick Release Hooks
The Elebia Drop Test Release Hook is designed for use with a dual remote control system.
We have chosen to implement a dual remote control setup, employing two emini remotes to enhance error mitigation.
Utilizing distinct frequencies for each remote adds an additional layer of security, making it more challenging for potential hackers to intercept and decipher the signals.
The likelihood of inadvertent order transmission is greatly reduced, given the necessity for precise button sequences on each remote within predefined time parameters.
For optimal operation, it is recommended to assign two separate workers to independently operate each remote.
You can see how it works our remote release hooks.
Shackle Integration with Drop Test Release Hook
Our quick release drop tester is supplied with a shackle. The Green Pin® Bow Shackle BN is a bow shackle with a safety bolt. The shackle offers a double safety (split pin and safety bolt) which prevents accidental unscrewing of the pin.
| Material | bow and pin high tensile steel, Grade 6, quenched and tempered |
| Safety Factor | MBL equals 6 x WLL |
| Finish | hot dipped galvanized |
| Temp. Range | -40°C up to +200°C |
| Diameter Pin | 35mm. / 1.37in. |
| Certification | 2.1 / 2.2 / 3.1 / MTCa / ABS PDA / ABS MA / |
| DNV 2.7-1a / DNV 2.7-1b / DNVGL-ST-0378 / CE | |
| Standard | N 13889 and meets performance requirements of |
| US Fed. Spec. RR-C-271, Type IVA, Class 3, Grade A. | |
| From 2 t and upward these shackles comply with ASME B30.26 |
Regulatory Standards for Quick Release Hook Drop Tests
Elebia’s D10 certifies with the following regulatory standards:
| EN ISO12100:2012 | EN 61000-6-4:2002 |
| EN 61000-6-2:2002 | EN 60204-1:2007 |
Directive on Machine Safety (D2006/42/EC).
EMC Directive (2014/30/EU).
Low Voltage Directive (2014/35/EU).
Radio Equipment Directive (2014/53/EU).
Assurance of Production Quality in accordance with ISO9001.
ARIB Construction Design Certification Number 203-JN0689.
FCC Identifier 2ACLHEVO for Equipment Class: Digital Transmission System.
Each mechanism is delivered with the CE stamp and a declaration of CE conformity.
elebia is a member of F.E.M. (European Federation of Materials Handling).
Quick Links for Our Quick Release Hook Drop Test
Configurator for Custom Quick Release Drop Testers
Personalize and configure
your D10 remote
load drop hook.
Schedule a Demo of Our Quick Release Drop Tester
See in person how your company
can benefit by using the
D10 load drop hook.
User Manual for Quick Release Hook Drop Test
All the info you need and
more, of the D10
remote Load Drop Hook.
Request a Quotation for Quick Release Drop Testers
Receive a quote for your
D10 Load Drop Hook or
any other product and accessory.
Quick FAQs about our D10 Drop Test Hook
What is a quick release hook drop test and why is it important?
A quick release hook drop test validates the hook’s functionality under load release conditions, ensuring safe operation. This remote-controlled hook allows the release of materials from a certain height, making it essential to operate remotely for personnel safety.
How does the remote load drop hook enhance safety during tests?
The remote load drop hook minimizes human involvement in tests, reducing the risk of accidents during load release scenarios.
Can the quick release drop tester be customized for specific applications?
Yes, the quick release drop tester can be customized to suit specific applications, providing flexible solutions for various testing needs.
What are the key features of the drop test release hook?
Key features include remote control capability, quick release, and a minimum release weight of 0 kg, allowing it to open without requiring a minimum load. It also includes a load cell to measure the weight suspended from the hook.
What safety measures are included in the quick release hook drop test?
Safety measures include remote operation and a Dual Remote Controlled Release for Quick Release Hooks. This dual remote setup uses two mini remotes, each on distinct frequencies, providing an extra layer of security. This approach minimizes the risk of interference or unintended command execution, as operators must press specific buttons on both remotes within a set time frame to release the load. It is recommended that two separate workers operate each remote independently for optimal safety.
